XY9000
XY9000 is a multi-system single frequence GNSS receiver.
XY9000 has the characteristics of low power consumption and high performance, suitable for trackers, IoT, GNSS modules, drones, and other applications.
Product Advantage
-
-
Multi-system joint positioning
Support BDS, GPS, Galileo, GLONASS, QZSS
-
High sensitivity
The acquisition sensitivity is greater than -148dBm, and the tracking sensitivity is greater than -165dBm.
-
Low-power consumption
L1 Continuous tracking mode: 20 mA
Sleep mode: 14 μA
-
AGNSS is supported.
-
Basic Parameter
-
-
Multi-system joint positioning
Support?GPS L1, Beidou B1I, Beidou B1C, Galileo E1, QZSS L1, GLONASS G1, SBAS L1
-
Processor
32-bit MCU
-
Encapsulation
QFN 4mm*4mm
-
Hardware peripheral
? 11 GPIOs
? 2x UART; 1x SPI; 1x I2C； -
Operating temperature
-40°C to +85°C
-
